New Concept Wheel Chair
Stress Analysis
As you can see front wheel holder we did stress analysis based on selected material ( AISI 1020 ).
The results shows the highest stress is 0.769 MPa . Much less than Sy
Sy= 325.0 MPa
Very safe design
